LCS-4034TP1C: 7-Segment Purple
14 PIN 0.40 Inch (10.16mm) LED Cathode
|
PRODUCT DESCRIPTION |
|
|
(1) 0.40 Inch (10.16mm) Digit Height |
(5) Low Current Operation |
|
(2) Common Cathode |
(6) Excellent color and Font Characteristics |
|
(3) Black Background |
(7) RoHS Compliant Part |
|
(4) Color: White, Blue, Red, Green, Purple, Orange,
Yellow |
Absolute Maximum Rating
(Ta = 250C)
|
PARAMETER |
WHITE |
UNITS |
|
DC Forward
Current Per Segment |
20 |
mA |
|
Peak Current
Per Segment (1) |
25 |
mA |
|
Avg. Forward Current
(Pulse Operation) Per Segment |
25 |
mA |
|
Reverse
Voltage (2) |
3 |
V |
|
Operating
Temperature |
-30
to +85 |
0C |
|
Storage
Temperature |
-30
to +85 |
0C |
(1) Pulse conditions of 1/10 duty and 0.1msec
width, for long operating life, max. of 20mA recommended
(2)
Reverse biasing of the dot matrix is not recommended, will damage the
leds
Electro-optical
Characteristics (Ta = 250C)
|
|
|
|
MAX. |
|
|
LUMINOUS INTENSITY |
|
LCS-4034TW1C |
InGaN |
5,500K |
10 |
2.8 |
3.6 |
85,000
ucd |
|
LCS-4034TB1C |
InGaN |
465nm |
10 |
2.8 |
3.6 |
68,000
ucd |
|
LCS-4034TP1C |
InGaN |
Purple |
10 |
2.8 |
3.6 |
78,000
ucd |
|
LCS-4034AUR1C |
AlInGaP |
625 |
10 |
1.8 |
2.2 |
48,000
ucd |
|
LCS-4034YG1C |
AlInGaP |
568 |
10 |
1.9 |
2.3 |
45,000
ucd |
|
LCS-4034UY1C |
AlInGaP |
590 |
10 |
1.8 |
2.3 |
45,000
ucd |
DEVICE
DIAGRAM
|
PIN NO. |
|
|
|
|
1 |
Anode A |
8 |
Anode D |
|
2 |
Anode F |
9 |
Anode DP |
|
3 |
Common Cathode DIG. 1 |
10 |
Anode C |
|
4 |
NO PIN |
11 |
Anode G |
|
5 |
NO PIN |
12 |
NO PIN |
|
6 |
NO PIN |
13 |
Anode B |
|
7 |
Anode E |
14 |
Common Cathode DIG. 2 |
|
LC LED Corporation |
