PRODUCT DESCRIPTION |
|
|
(1) RoHs Compliant Part |
(4) Bulk Packaging |
|
(2) SMD Assembly or Manual
Soldering |
(5) Ideal for All Backlighting Applications |
|
(3) Bin Sorted By Color,
Intensity & Vf |
|
Electro-optical
Characteristics (Ta = 250C)
|
|
|
Viewing |
lD |
Luminous Intensity |
Vf |
|||
|
P/N |
LED Color |
Angle |
Typ (nm) |
Min. |
Typ. |
Max. |
Typ. (V) |
Max (V) |
|
R2033TWW |
Warm
White |
170 |
3300K |
100 |
250 |
– |
3.0 |
3.7 |
|
R2033TW |
Super
White |
170 |
X=0.31 |
100 |
250 |
– |
3.0 |
3.7 |
|
R2033TB |
Super
Blue |
25 |
470 |
100 |
250 |
– |
3.0 |
3.8 |
|
R2033TG |
Aqua
Green |
25 |
525 |
100 |
250 |
– |
3.0 |
3.8 |
|
R2033TUR |
Super Red |
25 |
630 |
100 |
125 |
– |
1.8 |
2.3 |
|
R2033TY |
Super
Yellow |
25 |
592 |
90 |
100 |
|
1.7 |
2.1 |
Absolute Maximum
Rating (Ta = 250C)
|
Parameter |
Maximum Rating |
Units |
|
DC Forward Current |
30 |
mA |
|
Peak Pulse Current (1) |
100 |
mA |
|
Power Dissipation |
100 |
mW |
|
Reverse Voltage (IR = 100uA) |
5 |
V |
|
Operating Temperature |
-30 to
+85 |
0C |
|
Storage Temperature |
-30 to
+85 |
0C |
(1) Pulse Conditions of 1/10 duty and 0.1msec widths
|
LC LED Corporation |
