LCS-4034TW1C: 7-Segment White 14 PIN 0.40 Inch (10.16mm) LED Cathode

PRODUCT DESCRIPTION
(1) 0.40 Inch (10.16mm) Digit Height	(5) Low current operation
(2) Common Cathode	(6) Excellent color and font characteristics
(3) Black Background	(7) RoHs Compliant Part
(4) Color: White	(8) Custom configuration available

Absolute Maximum Rating (Ta = 25⁰C)

PARAMETER	WHITE	UNITS
DC Forward Current Per Segment	20	mA
Peak Current Per Segment (1)	25	mA
Avg. Forward Current (Pulse Operation) Per Segment	25	mA
Reverse Voltage (2)	3	V
Operating Temperature	-25 to +85	^0C
Storage Temperature	-30 to +85	^0C

(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended

(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds

Electro-optical Characteristics (Ta = 25⁰C)

PART NUMBER	DICE MATERIAL (COLOR)	PEAK WAVELENGTH (nm)	MAX. REVERSE CURRENT / SEGMENT (mA)	VF (V) TYP	VF (V) MAX.	LUMINOUS INTENSITY / SEGMENT AVERAGE (IF = 10mA)
LCS-4034TW1C	InGaN White	5,500K	10	3.3	4.0	20,000 ucd

DEVICE DIAGRAM

PIN NO.
1	Anode A	8	Anode D
2	Anode F	9	Anode DP
3	Common Cathode DIG. 1	10	Anode C
4	NO PIN	11	Anode G
5	NO PIN	12	NO PIN
6	NO PIN	13	Anode B
7	Anode E	14	Common Cathode DIG. 2
