LCS-4034AUR1C: 7-Segment Red 14 PIN 0.40 Inch (10.16mm) LED Cathode

PRODUCT DESCRIPTION



(1)  0.40 Inch (10.16mm) Digit Height

(5)  Low current operation

(2)  Common Cathode

(6)  Excellent color and font characteristics

(3)  Black Background

(7)  RoHs Compliant Part

(4) Color:  White

(8)  Custom configuration available





Absolute Maximum Rating (Ta = 250C)

PARAMETER

WHITE

UNITS

DC Forward Current Per Segment

20

mA

Peak Current Per Segment (1)

25

mA

Avg. Forward Current (Pulse Operation) Per Segment

25

mA

Reverse Voltage (2)

3

V

Operating Temperature

-25 to +85

0C

Storage Temperature

-30 to +85

0C

(1)  Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended

(2)  Reverse biasing of the dot matrix is not recommend, will cause damage to the leds





Electro-optical Characteristics (Ta = 250C)







PART NUMBER



DICE
MATERIAL
(COLOR)



PEAK
WAVELENGTH
(nm)

MAX.
REVERSE
CURRENT /
SEGMENT
(mA)




VF (V)
TYP




VF (V)
MAX.

LUMINOUS INTENSITY
/ SEGMENT
AVERAGE
(IF = 10mA)

LCS-4034TW1C

InGaN
White

5,500K

10

3.3

3.8

85,000 ucd

LCS-4034TB1C

InGaN
Blue

465nm

10

3.3

3.8

68,000 ucd

LCS-4034AUR1C

AlInGaP
Red

625

10

1.8

2.3

48,000 ucd

LCS-4034YG1C

AlInGaP
Green

568

10

1.9

2.3

45,000 ucd

LCS-4034UY1C

AlInGaP
Yellow

590

10

1.8

2.3

45,000 ucd





DEVICE DIAGRAM

PIN NO.







1

Anode A

8

Anode D

2

Anode F

9

Anode DP

3

Common Cathode DIG. 1

10

Anode C

4

NO PIN

11

Anode G

5

NO PIN

12

NO PIN

6

NO PIN

13

Anode B

7

Anode E

14

Common Cathode DIG. 2




LC LED Corporation
