LCD-3632AUR11:  7-Segment Red Double Digit 0.36 Inch (9.14mm) LED Display

PRODUCT DESCRIPTION



(1) Double Digit 0.36 Inch (9.14mm) Height

(5)  Black color background

(2) Low current operation

(6)  Common Anode

(3) Excellent color and font characteristics

(7)  RoHs Compliant Part

(4) Colors:  White, blue, red, yellow and green







Absolute Maximum Rating (Ta = 250C)

PARAMETER

RED

AMBER

GREEN

BLUE

UNITS

DC Forward Current Per Segment

30

30

25

30

mA

Peak Current Per Segment (1)

80

70

70

90

mA

Avg. Forward Current (Pulse Operation) Per Segment

30

30

25

30

mA

Derating Linear From 250C Per Segment

0.3

mA/0C

Reverse Voltage (2)

3

V

Operating Temperature

-25 to +85

0C

Storage Temperature

-0 to +100

0C

(1)  Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended

(2)  Reverse biasing of the dot matrix is not recommend, will cause damage to the leds





Electro-optical Characteristics (Ta = 250C)





PART NUMBER



DICE
MATERIAL
(COLOR)



PEAK
WAVELENGTH
(nm)

MAX.
REVERSE
CURRENT /
SEGMENT
(mA)




VF (V)
TYP




VF (V)
MAX.

LUMINOUS INTENSITY
/ SEGMENT
AVERAGE
(IF = 10mA)

LCD-3622AUR11

AlGaAs
Red

660

10

1.8

2.3

10,000 ucd

LCD-3622TB11

InGaN
Blue

468

10

3.3

4.0

20,000 ucd

LCD-3622YG11

GaP
Green

568

10

1.9

2.3

10,000 ucd

LCD-3622UY11

AlInGaP
Amber

590

10

1.8

2.3

10,000 ucd

LCD-3622TW11

InGaN
White

5,500K

10

3.3

4.0

20,000 ucd





First Digit Segment



Second Digit Segment

PIN



PIN





PIN



PIN



1

Cathode G1

6

Cathode D1



1

Cathode G2

6

Cathode D2

2

Cathode DP1

7

Cathode E1



2

Cathode DP2

7

Cathode E2

3

Cathode A1

8

Cathode C1



3

Cathode A2

8

Cathode C2

4

Cathode F1

9

Cathode B1



4

Cathode F2

9

Cathode B2

5

Common Anode 5

10

Common Anode 10



5

Common Anode 5

10

Common Anode 10





DEVICE DIAGRAM











































LC LED Corporation
